Unlocked by RF card.(cards can be printed hotel logo)
with mechanical keys for emergency
Support card type: Temic T5557 card,125KHZ or M1card, 13.56MHZ
Power supply:4X1.5V alkaline batteries(batteries not included)
Batteries life: about one year
DND(do not disturb)function is available
Issue authorization card, clock card, room number setting card, master card, emergency card, floor card, building card, guest card, temporary card, house keeping card, alarm card, no-disturbing card etc.
lock software,encoder,RF card,energy saver,data collector.
Can silver or golden colur
Lock external size:247x77x72mm
Technical data
1. Chip of pcb: adopting TI chips from American Texas Instruments
2. working temperature: -20℃～50℃
3. Static power consumption: ＜4μA
4. Dynamic power consumption: about 200mA
5. relative humidity: ＜95℃
4. Antistatic ability: ＞15000V stable, can still save data even under strong electrostatic interference
5. weight: 2.8～3.4KG for different items
6. unlocking record: the last 1000 pieces of unlocking records can be read.
7. induction distance: 3～5cm distance from the lock sensitive area to swipe.
8. unlocking method: contactless induction unlocking.
9 Low voltage alarm: if three times alarm sound and red light twinkle occur, it means the battery is at low voltage. You need to change to batteries in time. (door can be opened at least 200 time after first time alarm)
10. suitable door thickness: large, medium, and small types of mortise, can be installed on the door with 30～60mm thickness.
11. the mutual unlocking rate for one mechanical cylinder is 6‱（the mechanical cylinder can also be made as general type）, each lock matches 2 mechanical key for backup.
12. after Swipe card, press lock handle, or it will be locked after 6 seconds; if 6 seconds without locking the door after open the door, the lock buzzer will alarm to remind you lock door.
